Understanding the Differences in BLDC Motors: Inner vs. Outer Rotor Designs

Brushless DC (BLDC) motors have revolutionized the world of electric motors with their efficiency, reliability, and performance. Among the various types of BLDC motors, the inner and outer rotor designs stand out due to their unique configurations and applications. This article aims to elucidate the differences between inner and outer BLDC motors, highlight the main advantages of an outer rotor brushless motor design, and provide a glimpse into the intricate workings inside a brushless motor.

What is the Difference Between Inner and Outer BLDC Motors?

Inner rotor brushless motor

Inner rotor brushless motor are the most commonly used type in various applications. In this design, the rotor (the rotating part of the motor) is located inside the stator (the stationary part). The stator contains the windings, which are electromagnets that generate a rotating magnetic field when powered. This field interacts with the permanent magnets on the rotor, causing it to turn.

Advantages of Inner rotor brushless motor:

Higher RPM: Inner rotor motors typically achieve higher rotational speeds (RPM) due to the lower inertia of the rotor.

Compact Design: These motors are usually more compact, making them suitable for applications where space is limited.

Better Cooling: The stator windings are on the outside, allowing for better heat dissipation and cooling.

Applications of Inner rotor brushless motor:

● Power tools

● Robotics

● Drones

● Household appliances

Outer Rotor BLDC Motors

Outer rotor BLDC motors feature a reversed configuration where the rotor is on the outside, encircling the stator. The stator is fixed and contains the windings, while the rotor, equipped with permanent magnets, rotates around it.

Advantages of Outer Rotor BLDC Motors:

Higher Torque: The larger diameter of the rotor in outer rotor designs allows for greater torque production, making them ideal for applications requiring high torque at low speeds.

Stability: The higher inertia of the outer rotor provides more stability and smoother operation.

Lower RPM: Outer rotor motors tend to have lower rotational speeds, which is beneficial in applications where controlled, steady motion is required.

Applications of Outer Rotor BLDC Motors:

● Electric bicycles

● Conveyor systems

● Fans and blowers

● Direct-drive turntables

What is the Main Advantage of an Outer Rotor Brushless Motor Design?

The primary advantage of an outer rotor brushless motor design is its ability to produce higher torque at lower speeds. This characteristic is particularly beneficial in applications where smooth and controlled motion is paramount. The increased torque is due to the larger diameter of the rotor, which allows for a greater leverage effect when interacting with the magnetic field generated by the stator windings.

Additionally, the outer rotor design provides enhanced stability due to its higher inertia. This stability results in smoother operation, which is essential for applications such as electric bicycles, where consistent and reliable performance is crucial.

Another significant advantage is the efficient use of space. In an outer rotor motor, the motor's housing often doubles as the rotor, making it an integral part of the motor's structure. This integration can lead to more compact and efficient designs, particularly useful in applications like fans and blowers where space constraints are a concern.

What is the Inside of a Brushless Motor?

Understanding the inner workings of a brushless motor involves looking at its main components and how they interact to produce motion.

Stator

The stator is the stationary part of the motor and contains the windings. These windings are made of copper wire and are arranged in a specific pattern to create a magnetic field when an electric current passes through them. The number of windings and their configuration can vary, influencing the motor's performance characteristics.

Rotor

The rotor is the rotating part of the motor and contains permanent magnets. In an inner rotor design, the rotor is inside the stator, while in an outer rotor design, the rotor surrounds the stator. The magnets on the rotor interact with the magnetic field generated by the stator windings, causing the rotor to turn.

Electronic Speed Controller (ESC)

The ESC is a crucial component of a BLDC motor system. It controls the power supplied to the motor windings, determining the speed and direction of the motor. The ESC uses feedback from sensors (or sensorless algorithms) to adjust the current in the windings, ensuring efficient and precise control of the motor's operation.

Bearings

Bearings are essential for reducing friction between the rotating rotor and the stationary stator. High-quality bearings are critical for the smooth operation and longevity of the motor.

Hall Sensors (Optional)

Some BLDC motors include Hall sensors, which are used to detect the position of the rotor. This information is fed back to the ESC, allowing for more precise control of the motor. Sensorless BLDC motors rely on back EMF (electromotive force) to estimate the rotor position.

Conclusion

The choice between inner and outer rotor BLDC motors depends on the specific requirements of the application. Inner rotor motors are preferred for their high-speed capabilities and compact design, while outer rotor motors excel in producing high torque and providing stable, smooth operation. Understanding the advantages and internal workings of these motors can help in selecting the right motor for various applications.
